Comments: |
With lever |
Distance between holes |
1.57 in |
Electrical Connection |
Bayonet DIN 72585-A1-2.1-Sn/K2 |
Mounting |
2x Ø 0.436 in |
Operational range |
±50° |
Protection Class |
IP 6K9K |
Rated current (A) |
90 mA |
Temperature range |
-40 to + 185° F |
Type |
Inductive |
Type of lever |
Cross lever |
Voltage |
12 V |
Calculated Volume (dm³) |
0.6784 |
Size (mm x mm x mm) |
80 x 80 x 106 |
Weight (kg) |
0.131 |
Weight (lb) |
0.28881 |
Application: |
CNHTC, DAEWOO, DAF, EVOBUS, FAW, HYUNDAI, IRISBUS, IVECO, KIA, MAN, MERCEDES-BENZ, SCANIA |
CNHTCWG9925715101/1 CNHTCWG99257151011 DAEWOO3425002890 DAEWOO34250 02890 DAEWOOP34250 02890 DAF1524843 EVOBUSA0025426718 |
IVECO0025426718 KIA558508D000 MAN81259370040 MAN2T2616149 MERCEDES-BENZ0025426718 MERCEDES-BENZA0025426718 MERCEDES-BENZ41200708 SCANIA1448082 SCANIA1934585 |
FAW3614315-Y671/A HYUNDAI558508D000 HYUNDAI55850 8D000 IRISBUS41200708 IVECO41200708 |
