What does an air dryer do?
Technical specification: |
OE specification |
Cartridge type |
Desiccant Cartrige |
Comments |
Ports 21 and 22 for Voss push-in fittings |
Cut-out pressure |
12.5 bar |
Max. operating pressure |
13.0 bar |
Operational range |
1.3+0.7 bar |
Port thread 1 |
M22 x 1.5 JED-152 |
Port thread 21 |
M22 x 1.5 JED - 388 |
Port thread 22 |
M16 x 1.5 JED - 388 |
Silencer |
No (432 407 012 0 retrofittable) |
Temperature range |
-40°C to +65°C |
Unloader |
Yes |
Calculated Volume (dm³) |
6.7645 |
Size (mm x mm x mm) |
258 x 167 x 157 |
Weight (kg) |
3.573 |
Weight (lb) |
7.8771 |
Application: |
DAF,MAN,NEOPLAN,PACCAR |
DAF 1517967 MAN 81521026097 MAN81521026101 MAN 81521026107 MAN 81521026020 MAN 81521026022 |
MAN 81521026024 MAN 81521026037 MAN 81521026060 NEOPLAN 81521026097 PACCAR 1517967 |
