Distance between bolts: |
80.0 x 80.0 mm |
Electrical connection: |
Bayonet DIN 72585 |
Max. operating pressure: |
8.5 bar |
Mounting: |
3x M8 |
Port thread 11: |
M22 x 1.5 JED - 388-4 |
Port thread 21: |
M22 x 1.5 JED - 388-0 |
Port thread 22: |
M22 x 1.5 JED - 388-0 |
Port thread 3: |
Integrated Silencer |
Port thread 42: |
M16 x 1.5 JED-388-0 |
Port thread 43: |
M16 x 1.5 JED-388-0 |
Protection class: |
IP 6K6K / IP 6K9K |
Rated current: |
1400 mA |
Technical specification: |
OE specification |
Temperature range: |
-40°C to +80°C |
Voltage |
24 V |
Calculated Volume (dm³) |
5.4134 |
Size (mm x mm x mm) |
176 x 169 x 182 |
Weight (kg) |
2.978 |
Weight (lb) |
6.5654 |
DAEWOO :3454403480 DAEWOO:34544 03480 DAEWOO:P34544 03480 DAF:1601034 DAF:0004319413 DAF:1315695 DAF:4103223 DAF:41211417 DAF:81523016208 EVOBUS:A0004319413 HYUNDAI:597107K000 HYUNDAI:59710 7K000 IRISBUS:41211417 ISUZU:1482401911 IVECO:41211417 IVECO:41032232 IVECO:0004319413 IVECO:1315695 IVECO:1601034 IVECO:4103223 IVECO:81523016208 LEYLAND DAF:1601034 MAN:81523016208 MAN:81923016216 MAN:0004319413 MAN:1315695 MAN:1601034 |
MAN:4103223 MAN:41211417 MERCEDES-BENZ0004319413 MERCEDES-BENZA0004319413 MERCEDES-BENZ1315695 MERCEDES-BENZ1601034 MERCEDES-BENZ4103223 MERCEDES-BENZ41211417 MERCEDES-BENZ81523016208 NEOPLAN81523016208 PACCAR1601034 SCANIA1935136 SCHMITZ CARGOBULL1042024 SCHWARZMÜLLER97456 SHAANXIDZ95259364002 SOLARIS1102219001 UD TRUCKS4528900Z05 VAN HOOL11167595 VDL297659 VDL20297659
|
